Commissioning Manual
01/2017
451
3
Axis/spindle
enable
program
test
Veloci-
ty/spindle
speed limit-
ing
Activate fixed feedrate
Enable
approach to
fixed stop
Feed 4 Feed 3 Feed 2 Feed 1
4
Traversing keys
Rapid trav-
erse over-
ride
Traverse
key disable
Feedrate
stop/spindle
stop
Activate handwheel
Plus Minus 2 1
5
Machine function
1)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
6
7 Contour-
handwheel
direction of
rotation
inverted
8
9
10
11
1)
The machine function is only entered if the signal "INC inputs in the operating-mode signal range active"
(DB2600.DBX1.0) is not set.
Signals to axis
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000 Delay Ref.
pt. ap-
proach
Module limit
enabled
Software limit switch
Hardware limit switch
Plus Minus Plus Minus
1001
1002 Activate
program
test
Suppress
program
test
1003
Signals to spindle
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2000 Delete S
value
No speed
monitoring
for gear
change
Resynchronize spindle
Gear
changed
Actual gear stage
2 1 C B A
2001 Invert
M3/M4
Resynchro-
nize during
positioning
Feedrate
override for
spindle
valid
2002 Setpoint direction of rota-
tion
Oscillation
speed
Oscillation
controlled
by PLC
Counter-
clockwise
Clockwise
