Page #189 background imageLoading...
Page #189 background image
Commissioning Manual
01/2017
189
Name
Type
Description
Tm_Chg
WORD
Tool change monitor time (unit: 0.1s)
T_1
BOOL
T code A
T_2
BOOL
T code B
T_3
BOOL
T code C
T_4
BOOL
T code D
Parity
BOOL
Parity bit
Strobe
BOOL
Tool on position signal
OVload
BOOL
Turret motor overload (NC)
P_Indx
BOOL
Turret pre-indexing sensor
T_key
BOOL
Manual key for tool change
Outputs
Name
Type
Description
T_cw
BOOL
Turret CW rotation output
T_ccw
BOOL
Turret CCW rotation output
Magent
BOOL
Solenoid for clamping
T_LED
BOOL
Display for tool changing
ERR1
BOOL
Error1: turret motor overload
ERR2
BOOL
Error2: programmed tool no. > max tool no.
ERR3
BOOL
Error3: max tool no. setting error
ERR4
BOOL
Error4: not able to find pre-indexing signal in expected time
ERR5
BOOL
Error5: not able to lock in expected time
Assigned global variables
T_CURRENT
VD14000064
Current tool (retentive data)
T_cw_m
M156.0
Position marking for turret CW rotation
T_ccw_m
M156.1
Position marking for turret CCW rotation
T_P_INDX
MD160
Monitoring the tool change buffer zone in JOG mode
T_DES
M164
Desired tool number
T_DIR
M168.0
Direction of adjacent tool change
T_POS
M168.1
Turret tool positioning finished
T_LOCK
M168.2
Turret clamping command
T_MAG
M168.3
Turret magnetic clamping
Relevant PLC machine data
No.
Unit
Description
14510 [20]
-
Max. tool number (4 or 6)
14510 [21]
0.1 s
Turret clamping time
14510 [22]
0.1 s
Monitoring time for tool searching
14512 [17].0
-
Activating the turret function of a turning machine
14512 [21].1 - Switch of the I/O interface (0: set I0.0 to I2.7/Q0.0 to Q1.7 as the standard I/O wiring in
the default PLC; 1: set I6.0 to I8.7/Q4.0 to Q5.7 as the standard I
/O wiring in the default
PLC)
