Encoder type and resolution
⑫
Rated power
⑲
Motor operating mode
⑥
Maximum current
⑬
Motor power factor
⑦
Rated voltage
⑭
Weight
Explanation of the SIMOTICS M-1PH1 main motor article numbers
Data position of the article
number
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Article number
1
P
H
1
❑
❑
❑
-
●
❑
❑
●
❑
-
❑
●
●
●
Shaft height
100 mm
1
0
132 mm
1
3
Rated power and speed
(SH100)
3.7 kW, 1500 rpm
1
3.7 kW, 1000 rpm;
5.5 kW, 1500 rpm
3
5.5 kW, 1000 rpm;
7.5 kW, 1500 rpm
5
Rated power and speed
(SH132)
7.5 kW, 1000 rpm;
11 kW, 1500 rpm
1
11 kW, 1000 rpm;
15 kW, 1500 rpm
3
Asynchronous variant
1
Encoder type
Incremental encoder, TTL
2500 ppr
L
Rated speed
1000 rpm
D
1500 rpm
F
Forced cooling (non-drive
end to drive end)
1
Type of construction
IM B3/IM V5, foot mounting
0
IM B5/IM V1, flange
mounting
2
Shaft extension
Plain shaft
0
Fitted key, full-key balancing
1
Fitted key, half-key balanc-
ing
2
Standard bearing
G
Mechanics
A
Version
0
