Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
340 01/2017
Tag identifier
Meaning
PROPERTY
This tag can be used to define additional properties for an operator control.
Attributes:
•
max
= "<maximum value>"
•
min
= "<minimum value>"
•
default
= "<pre-assignment>"
•
factor
= "conversion factor"
•
color_bk
= "<background color coding>"
•
color_fg
= "<font color coding>"
•
password
= "<true>" - entered character is displayed with "*"
•
disable
= "<true/false>" - locks/permits the input in an edit control
•
transparent
= "Transparent color of a bitmap"
Color coding (see Chapter "Color coding (Page 323)")
•
tooltip
= information text is displayed if the cursor is set to the control.
The syntax is: <property tooltip="note text" />
•
abscissa
= "Name of the first coordinate axis" (only permissible for a graphic box)
•
ordinate
= "Name of the second coordinate axis" (only permissible for a graphic box)
Example:
<CONTROL name = "progress1" xpos = "10" ypos = "10" width = "100"
fieldtype = "progressbar" hotlink = "true" refvar =
"nck/Channel/GeometricAxis/actProgPos[1]">
<PROPERTY min = "0" />
<PROPERTY max = "1000" />
</CONTROL>
<CONTROL name = "edit1" xpos = "10" ypos = "10">
<PROPERTY min = "20" />
<PROPERTY max = "40" />
<PROPERTY default = "25" />
</CONTROL>
