Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
351
Tag identifier
Description
CREATE_CYCLE
The tag generates an NC block, whose syntax is defined by the value of the
NC_INSTRUCTION
tag.
Before generating the NC instruction, the parser calls the
CYCLE_CREATE_EVENT tag of the FORM. This tag can be used to calculate
the cycle parameters.
Syntax:
<CREATE_CYCLE/>
Option:
If a reference variable is specified, the instruction copies the generated call into
this variable.
<create_cycle refvar="name" />
Attribute:
•
refvar
If the tag is assigned a reference variable, the NC instruction is copied to this
variable.
Example:
<LET name="cyc_string" type="string"> Cycle100(0, 1000,
5)</LET>
<SOFTKEY_OK>
<caption>OK</caption>
<CREATE_CYCLE />
<close_form />
<navigation>main_menu</navigation>
</SOFTKEY_OK>
or
<SOFTKEY_OK>
<caption>OK</caption>
<CREATE_CYCLE refvar= "cyc_string" />
<close_form />
<navigation>main_menu</navigation>
</SOFTKEY_OK>

Siemens SINUMERIK 808D ADVANCED Specifications

General

Control Type	CNC
Input Voltage	24 V DC
Minimum programmable increment	0.001 mm
Spindle Control	Yes
Interface	USB
Programming Language	G-code
Display	7-inch TFT color display
Interfaces	USB
PLC	Integrated
Programming	G-code
Protection Class	IP20
