Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
417
Data type
Type
Description
I16
16-bit integer
I32
32-bit integer
U16
16 bits without sign
U32
32 bits without sign
Uint16
16-bit unsigned integer
Uint32
32-bit unsigned integer
Float
32-bit floating point number
Calling help information for V70 parameters
You can call the help information for the V70 drive parameters on the PPU by proceeding through the following steps:
+
1.
Select the sys
tem data operating area.
2.
Press this softkey to o
pen the machine data window.
3.
Open the drive data list through the following softkey operations:
→
4.
Select the desired parameter using the cursor keys.
5.
Press this key to call the help information for the selected parameter.
Note:
You can further press this softkey in the current help screen to show a com
plete list of
all SINAMICS V70 parameters. In addition, you can also use the foll
o
wing softkey to search
for a specific parameter by number in this list:
6.
Pressing this softkey exits the help system.
