Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
420 01/2017
Par. No.
Name
Min
Max
Factory
setting
Unit
Data type
Effective
Can be
changed
r0079[0...1]
Torque setpoint total
-
-
-
Nm
Float
-
-
Description:
Displays the torque setpoint at the output of the speed controller (before clock cycle interpola-
tion).
• [0]: Unsmoothed
•
[1]: Smoothed
r0632 Motor temperature model,
stator winding temperature
- - - °C Float - -
Description: Displays the stator winding temperature of the motor temperature model.
p0918
Drive Bus address
10
15
10
-
U16
RE
T
Description:
Displays or sets the Drive Bus address for Drive Bus interface on the servo drive.
The address can be set as follows:
Using p0918
• Only if the address 00 hex, 7F hex, 80 hex, or FF hex has been set using the address switch.
• The address is saved in a non-volatile fashion using the function "copy from RAM to ROM".
•
A change only becomes effective after a POWER ON.
p1058 Jog 1 speed setpoints 0 210000.0
00
100 rpm Float IM T
Description:
Sets the speed/velocity for jog 1. Jogging is level-triggered and allows the motor to be incre-
mentally moved.
p1082 Maximum speed 0.000 210000.0
00
1500.00
0
rpm Float IM T
Description: Sets the highest possible speed.
Dependency: p0322
p1083 Speed limit in positive direc-
tion of rotation
0.000 210000.0
00
210000.
000
rpm Float IM T, U
Description: Sets the maximum speed for the positive direction.
p1086 Speed limit in negative
direction of rotation
-
210000.0
00
0.000 -
210000.
000
rpm Float IM T, U
Description: Sets the speed limit for the negative direction.
p1120 Ramp-function generator
ramp-up time
0.000 999999.0
00
10.000 s Float IM T, U
Description:
The ramp-function generator ramps-up the speed setpoint from standstill (setpoint = 0) up to
the maximum speed (p1082) in this time.
Dependency: p1082
p1121 Ramp-function generator
ramp-down time
0.000 999999.0
00
10.000 s Float IM T, U
Description:
The ramp-function generator ramps-down the speed setpoint from the maximum speed
(p1082) down to standstill (setpoint = 0) in this time.
Further, the ramp-down time is always effective for OFF1.
Dependency: p1082
p1215 Motor holding brake config-
uration
0 3 0 - I16 IM T
Description:
Sets the holding brake configuration.
• 0: No motor holding brake being used
• 1: Motor holding brake according to sequence control
• 2: Motor holding brake always open
•
3: Motor holding brake like sequence control
Dependency: p1216, p1217, p1226, p1227, p1228
