Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
488 01/2017
Fault
Cause
Remedy
F1002: Internal software
error
Reaction: OFF2
Acknowledgement:
IMMEDIATELY
An internal software error has occurred.
• Carry out a POWER ON (power off/on) for
all components.
• Upgrade firmware to the latest version.
• Contact the Hotline.
F1003: Acknowledgement
delay when accessing the
memory
Reaction: OFF2
Acknowledgement:
IMMEDIATELY
A memory area was accessed that does
not return a "READY".
•
Carry out a POWER ON (power off/on) for
all components.
• Contact the Hotline.
F1015: Internal software
error
Reaction: OFF2
Acknowledgement: POWER
ON
An internal software error has occurred.
• Carry out a POWER ON (power off/on) for
all components.
• Upgrade firmware to the latest version.
• Contact the Hotline.
F1018: Booting has been
interrupted several times
Reaction: NONE
Acknowledgement: POWER
ON
Module booting was interrupted several
times. As a consequence, the module
boots with the factory setting.
Possible reasons for booting being inter-
rupted:
• Power supply interrupted.
• CPU crashed.
• Parameterization invalid.
After this fault is output, then the module is
booted with the factory settings.
•
Carry out a POWER ON (power off/on).
After switching on, the module reboots from
the valid parameterization (if available).
• Restore the valid parameterization.
Examples:
• Carry out a first commissioning, save, carry
out a POWER ON (switch-off/switch-on).
• Load another valid parameter backup (e.g.
from the memory card), save, carry out a
POWER ON (switch-off/switch-on).
Note:
If the fault situation is repeated, then this fault
is again output after several interrupted boots.
F1030: Sign-of-life failure for
master control
Reaction: OFF3
Acknowledgement:
IMMEDIATELY
For active PC master control, no sign-of-
life was received within the monitoring
time.
Contact the Hotline.
F1611: SI CU: Defect de-
tected
Reaction: OFF2
Acknowledgement:
IMMEDIATELY
The drive-integrated "Safety Integrated"
(SI) function on the Control Unit (CU) has
detected an error and initiated an STO
• Carry out a POWER ON (power off/on) for
all components.
• Upgrade software.
• Replace the Control Unit.
F1910: Drive Bus: Setpoint
timeout
Reaction: OFF3
Acknowledgement:
IMMEDIATELY
The reception of setpoints from the Drive
Bus interface has been interrupted.
• Bus connection interrupted.
• Controller switched off.
•
Controller set into the STOP state.
Restore the bus connection and set the con-
troller to RUN.
F1911: Drive Bus clock cycle
synchronous operation clock
cycle failure
Reaction: OFF1
Acknowledgement:
IMMEDIATELY
The global control telegram to synchronize
the clock cycles has failed - in cyclic oper-
ation - for several Drive Bus clock cycles
or has violated the time grid specified in
the parameterizing telegram over several
consecutive Drive Bus clock cycles.
• Check the physical bus configuration (ca-
ble, connector, Drive Bus terminator,
shielding, etc.).
• Check whether communication was briefly
or permanently interrupted.
• Check the bus and controller for utilization
level (e.g. bus cycle time was set too
short).
