Siemens SINUMERIK 808D ADVANCED

Commissioning Manual
506 01/2017
②
Use the following key to select the a
utomatic response for the control system after the
above dialog box disappears with no softkey operations.
6.
Press this softkey to save the settings.
Starting/stopping remote control
Proceed through the following steps to start/stop the remote control of the HMI:
1.
Start the AMM tool and establish an Ethernet connection to the control system (see sectio
n
"Connecting with AMM (Page 51)").
2.
Click the
button in the toolbar or select from the main window menu as follows to start the re-
mote control.
Once the remote control has been started, a monitoring window opens showing the HMI screen
contents
of the connected control system. You can find a symbol in the tip area of the HMI
screen.
3.
Closing the monitoring window or selecting from the main window menu as follows stops the r
e-
mote control.
