Ethernet communication
7.5 MCP 483C IE
Manual
Commissioning Manual, 05/2008, 6FC5397–4CP10–4BA0
195
Switch S2
Switch S2 is used to set the address by which the MCP is addressed by the PLC user
program:
Table 7-1 Switch S2: MCP address (1-8)
10
9
8
7 6 5 4 3 2 1 Meaning/value
off off - - - - - - - - Reserved
MCP address
- - off off off off off off off off 0
- - off off off off off off off on 1
- - off on off off off off on off 2
- - off off off off off off on on 3
- - : : : : : : : : :
- - on on off off off off off off 192 (on delivery)
- - : : : : : : : : :
- - on on on on on on on off 254
- - on on on on on on on on 255
7.5.3 MCP functions
The MCP offers the following functions:
● Standard
The input/output data of the MCP 483 is compatible with the input/output data from the
PROFIBUS MCP: MCP 483 and MCP 310.
● Handwheel
Up to 2 handwheels can be connected to the MCP. For each handwheel the current
handwheel value is transferred as a 16-bit absolute value relative to the starting value.
The starting value for the sensor counter in the handwheel is 0.
● Additional I/Os
Cover the additional I/Os:
– Customer keys (KT1 to KT9)
– Customer key outputs (KT_OUT1 to KT_OUT6)
– RESET output (R14_LED)
– Rotary switch (X31)
