Siemens SINUMERIK 840Di sl Commissioning Manual

Drive Optimization with HMI Advanced
14.9 Automatic controller setting
Manual
538 Commissioning Manual, 05/2008, 6FC5397–4CP10–4BA0
14.9 Automatic controller setting
14.9.1 Drives: SINAMICS S120
Functionality
The automatic controller setting of the speed control loop offers the following functionality:
● Determining the gain and reset time in these cases:
– Standard setting
– Critical damping
– Good damping
● Determining current setpoint filters which may be required
● Display of the measured or calculated frequency responses
&+$1
03)
;
529


PP
&RPPLV
VLRQLQJ
-2*5HI
$[LV
$[LV
'LUHFW
VHOHFWLRQ
6WDUW
6WRS
650$[LV
3URJUDPDERUWHG
&KDQQHO5(6(7
$XWRPDWLFFRQWUROOHUVHWWLQJ
'ULYHದWHVWWUDYHOHQDEOH
ZLWKRXW3/&
7UDYHUVLQJUDQJH
0RQLWRULQJ ,QDFWLYH
8SSHUOLPLW
/RZHUOLPLW
PP
PP
6WDWXV
,QDFWLYH
$EVROXWHSRVLWLRQ
)LOH
IXQFWLRQV
'LVSOD\
8VHU
YLHZV
'ULYH
0'
6HUYLFH
GULYH
6HUYLFH
D[LV
$XWFRQ
WUROOHUVHWWLQJ
0HDVXUHGYDULDEOH
7RUTXHDFWXDOYDOXHWRUTXHVHWSRLQW
0RGH
6HWWLQJW\SH
6SHHGFRQWUROOHU6WDQGDUGVHWWLQJ
Figure 14-16 Menu: Automatic controller setting
Operating path
Operating path of the automatic controller setting: Operating area switchover >
Commissioning > Optimization/Test > ">" > Automatic Controller Setting
