Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
146 Operating Manual, 06/2017, A5E31930478-05
Table 6- 21 Function assignment at function (pre-selection): "AutoCal"
AutoCal1/
AutoCal2
1)
Start AutoCal 1 or AutoCal 2.
AutoVal1/
AutoVal2
1)
Start AutoVal 1 or AutoVal 2.
AutoCal1 Sync./
AutoCal2 Sync.
(Function cannot
currently be execut-
Positive edge
1)
Start AutoCal n/AutoVal n in sync.
Starting an AutoCal/AutoVal that is used on several networked devices
(chain) synchronously. To do so, one sync input and one sync output must
be assigned per device.
The sync. indicates the start/end of a gas purge. With a 2-point calibration,
two sync sequences determine one single AutoCal sequence step. If such a
2-point calibration does not apply to one device in the chain, assign a pas-
sive calibration for the corresponding steps.
AutoVal1 Sync./
AutoVal2 Sync.
(Function cannot
currently be execut-
ed)
Positive edge
1)
1)
"Edge triggered": Activation by rising signal edge.
Table 6- 22 Function assignment at function (pre-selection): "Measuring range"
Measuring range
1 to 4
1)
Positive/negative
3)
If the measuring range is not controlled according to the parameter assign-
ment but by means of a digital input: the measuring rang signaled as active
by the digital input is used ("Measuring range 1 to 4" or autoranging).
If no digital input is active, the measuring ranges of the parameter assign-
ment are used accordingly.
If several digital inputs are active, the following prioritization applies: Meas-
uring range 4 → measuring range 3 → measuring range 2 → measuring
range 1 → autoranging.
Autoranging
2)
Positive/negative
3)
Switch measuring range 1 to 4.
Activate autoranging.
3)
"Level-triggered": Activation by rising signal edge, deactivation by falling signal edge. Active at signal level "High".
