Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
159
Table 6- 34 Function (pre-selection) "DI links"
Function (pre-
selection)
Purpose/resulting settings
DI link Switch linked digital inputs.
1. "Function" parameter box:
Authorize access with corresponding PIN, if necessary.
2. Select one of the displayed links.
Additional linking properties are:
– Type of logical operation (AND/OR)
– Combining inputs
Table 6- 35 Function (pre-selection) "Other functions"
Function (pre-
selection)
Purpose/resulting settings
Other functions Set additional functions.
1. "Function" parameter box:
Authorize access with corresponding PIN, if necessary.
2. Select one of the offered functions:
– Sync. (Function cannot currently be executed): Synchronization of Au-
toCal sequences between several devices.
– Calibration: Total function check: signaling of "Calibration" operating
state at device level.
– Calib. AM1/AM2: Signaling of "Calibration" operating state at module
level.
– Pump on/off: Switch external sample gas pump on/off.
– Funct. check: Signal function check at device level.
– Funct. check AM1/AM2: Signal function check at module level.
– Signaling contact: Signaling contact: AutoCal signal contact, pulse
1000 ms.
See also
Functions (Page 153)
