Siemens SIPROCESS GA700 User Manual

Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
158 Operating Manual, 06/2017, A5E31930478-05
Table 6- 31 Function (pre-selection) "Measuring ranges"
Function (pre-
selection)
Purpose/resulting settings
Measuring ranges Specify measuring range to be displayed.
1. "Component" parameter box:
– Authorize access with corresponding PIN, if necessary.
– Select available component.
2. "Function" parameter box:
Select one of the four available measuring ranges.
Table 6- 32 Function (pre-selection) "Process tags"
Function (pre-
selection)
Purpose/resulting settings
Process tags Output measured value of the used process tag.
1. "Function" parameter box:
Authorize access with corresponding PIN, if necessary.
2. Select one of the offered process tags.
Table 6- 33 Function (pre-selection) "Solenoid valves"
Function (pre-
selection)
Purpose/resulting settings
Solenoid valves Switch gas paths.
1. "Component" parameter box:
– Authorize access with corresponding PIN, if necessary.
– Select available component.
2. "Function" parameter box:
Set the following alternative gas paths:
– Sample gas
– Zero gas measuring ranges 1 to 4 (MR1 to MR4)
– Span gas measuring ranges 1 to 4 (MR1 to MR4)
