Siemens SIPROCESS GA700 User Manual

Appendix
A.5 MODBUS TCP
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
291
Object ID
Object name / description
Category
Type
Object
length
Coding
0xA8 Flow1_UnitCode Extended UINT16 0x02 Table A-16 MODBUS TCP: Cod-
ing of process value type [Object
ID 0x9F, 0xA1, 0xA3, 0xA5, 0xA7,
0x003C, 0x0049, 0x0054,
0x0060, 0x006C, 0x0078]
(Page 299)
0xA9 Flow2_Type Extended UINT8 0x01 Table A-17 MODBUS TCP: Cod-
ing of process value units [Object
ID 0xA0, 0xA2, 0xA4, 0xA6, 0xA9,
0x003D, 0x004A, 0x0055,
0x0061, 0x006D, 0x0079]
(Page 299)
0xAA Flow2_UnitCode Extended UINT16 0x02 Table A-16 MODBUS TCP: Cod-
ing of process value type [Object
ID 0x9F, 0xA1, 0xA3, 0xA5, 0xA7,
0x003C, 0x0049, 0x0054,
0x0060, 0x006C, 0x0078]
(Page 299)
Function Code 43
- Read Device Identification
Table A- 13 Measured values and diagnostics data
Address
Name / description
Register type
R/W
Type
Coding
0x0000 Component1_Code Input / holding R UINT8 Table A-16
MODBUS TCP: Coding
of process value type
[Object ID 0x9F, 0xA1,
0xA3, 0xA5, 0xA7,
0x003C, 0x0049,
0x0054, 0x0060,
0x006C, 0x0078]
(Page 299)
0x0001 Component1_UnitCode Input / holding R UINT16 Table A-17
MODBUS TCP: Coding
of process value units
[Object ID 0xA0, 0xA2,
0xA4, 0xA6, 0xA9,
0x003D, 0x004A,
0x0055, 0x0061,
0x006D, 0x0079]
(Page 299)
0x0002
Component1_MeasValue
Input / holding
R
FLOAT32
DECIMAL
0x0003
0x0004
Component1_Status
1)
Input / holding
R
UINT32
Bit-Enum
0x0005
0x0006
Component1_Factor
Input / holding
R
FLOAT32
DECIMAL
0x0007
