Appendix
A.5 MODBUS TCP
Operating with the Local User Interface
292 Operating Manual, 06/2017, A5E31930478-05
Address
Name / description
Register type
R/W
Type
Coding
0x0008
Component1_Offset
Input / holding
R
FLOAT32
DECIMAL
0x0009
0x000A
RESERVED
0x000B RESERVED
0x000C Component2_Code Input / holding R UINT8 Table A-16
MODBUS TCP: Coding
of process value type
[Object ID 0x9F, 0xA1,
0xA3, 0xA5, 0xA7,
0x003C, 0x0049,
0x0054, 0x0060,
0x006C, 0x0078]
(Page 299)
0x000D Component2_UnitCode Input / holding R UINT16 Table A-17
MODBUS TCP: Coding
of process value units
[Object ID 0xA0, 0xA2,
0xA4, 0xA6, 0xA9,
0x003D, 0x004A,
0x0055, 0x0061,
0x006D, 0x0079]
(Page 299)
0x000E Component2_MeasValue Input / holding R FLOAT32 DECIMAL
0X000F
0x0010 Component2_Status
1)
Input / holding R UINT32 Bit-Enum
0x0011
0x0012
Component2_Factor
Input / holding
R
FLOAT32
DECIMAL
0x0013
0x0014
Component2_Offset
Input / holding
R
FLOAT32
DECIMAL
0x0015
0x0016
RESERVED
0x0017
RESERVED
0x0018 Component3_Code Input / holding R UINT8 Table A-16
MODBUS TCP: Coding
of process value type
[Object ID 0x9F, 0xA1,
0xA3, 0xA5, 0xA7,
0x003C, 0x0049,
0x0054, 0x0060,
0x006C, 0x0078]
(Page 299)
0x0019 Component3_UnitCode Input / holding R UINT16 Table A-17
MODBUS TCP: Coding
of process value units
[Object ID 0xA0, 0xA2,
0xA4, 0xA6, 0xA9,
0x003D, 0x004A,
0x0055, 0x0061,
0x006D, 0x0079]
(Page 299)
