Description
3.6 Combined operation
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
41
Note
Order additionally required clamping screws separately
Additionally required clamping screws are not included in the scope of delivery. They must
be ordered separately.
Table 3- 5 Mounting conditions for the sample gas restrictor: OXYMAT 7
Sample gas restrictor/clamping screw
Operation with one
OXYMAT 7
Operation with two
OXYMAT 7 in series
Operation with two
OXYMAT 7 in parallel
Pressure operation In front of the sample
gas inlet
In front of the sample
gas inlet into which the
sample gas is intro-
duced first:
• Replace the sample
gas restrictor in the
inlet of the rear, se-
cond module with a
clamping screw
In front of each sample
gas inlet
Suction operation In the sample gas outlet
from which the sample
gas is first sucked out:
• Replace the sample
gas restrictor in the
inlet of the rear, se-
cond module with a
clamping screw
At each sample gas
outlet
