Description
3.6 Combined operation
Operating with the Local User Interface
42 Operating Manual, 06/2017, A5E31930478-05
Combination operation with ULTRAMAT 7
Table 3- 6 Mounting conditions for the sample gas restrictor: ULTRAMAT 7
Sample gas restrictor/clamping screw
Operating mode
Combined operation
OXYMAT 7/ULTRAMAT 7
Combined operation
ULTRAMAT 7/ULTRAMAT 7
Pressure operation
1. OXYMAT 7 must always be
purged first.
2. Install sample gas restrictor in
front of the sample gas inlet of
the OXYMAT 7.
No measures
Suction operation
1. ULTRAMAT 7 must always be
purged first.
2. Install sample gas restrictor in
the sample gas outlet of the
OXYMAT 7.
3. Provide sample gas inlet with
clamping screw.
No measures
CALOMAT 7
Table 3- 7 Mounting conditions for the sample gas restrictor: CALOMAT 7
Sample gas restrictor/clamping screw
Operating mode
Operation with one CALOMAT 7
Pressure operation
• Pre-assembled clamping screws. No retrofitting or dismantling.
Suction operation
