Binary Inputs Binary Inputs
19 V Threshold
1)
88 V Threshold
3)
176 V Threshold
3)
BI11 X29/X30 L M H
BI12 X31/X32 L M H
BI13 X33/X34 L M H
BI14 X35/X36 L M H
1)
Factory settings for devices with rated power supply voltages of DC 24 V to 125 V
2)
Factory settings for devices with rated power supply voltages of DC 110 to 220 V and AC 115 V to 230 V
3)
Use only with control voltages 220 V or 250 V
Contact Mode
With models 7VE63 binary output BO12 can be changed from normally open to normally closed operation.
The following table shows the setting of jumper X40 regarding the contact mode.
Table 3-9 Jumper settings for Contact mode of the binary output BO12 on the C–I/O-1 board
Jumper Open in quiescent state Closed in quiescent state Presetting
X40 1–2 2–3 1–2
Bus address
Jumpers X71, X72 and X73 on the Input/Output C-I/O-1 board are used to set the bus address and may not be
changed. The following Table shows the factory setting of the jumpers.
Table 3-10
Jumper settings for Bus address on the C–I/O–1 board for 7VE63
Jumper Presetting
X71 H
X72 L
X73 H
Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC 4, 7VE61 and 7VE63, Manual 153
C53000-G1176-C163-3, Edition 10.2017
