Page #197 background imageLoading...
Page #197 background image
9 – 97
Basic Data Type 3 Registers and Default Data Points
Register Byte Name Liefereinstellung für Datenpunkte - WL Default Data Point – WL
1 0, 1 Status Register WL Status-Bits WL status bits
2 2, 3 Data Block 1 Strom Phase L1 Phase 1 current
3 4, 5 Data Block 2 Strom Phase L2 Phase 2 current
4 6, 7 Data Block 3 Strom Phase L3 Phase 3 current
5 8, 9 Data Block 4 Strom der höchstbelasteten Phase Max current in phase under highest load
6 10, 11 Data Block 5 Strom im Neutralleiter Current in neutral conductor
7 12, 13 Data Block 6 Verkettete Spannung L1 nach L2 Phase to phase voltage L1 to L2
8 14, 15 Data Block 7 Verkettete Spannung L2 nach L3 Phase to phase voltage L2 to L3
9 16, 17 Data Block 8 Verkettete Spannung L3 nach L1 Phase to phase voltage L3 to L1
10 18, 19 Data Block 9 Sternpunktspannung L1 Phase to neutral voltage L1
11 20, 21 Data Block 10 Sternpunktspannung L2 Phase to neutral voltage L2
12 22, 23 Data Block 11 Sternpunktspannung L3 Phase to neutral voltage L3
13 24, 25 Data Block 12 Mittelwert des Leistungsf
aktors der 3 Phasen Average of power factors of 3 phases
14 26, 27 Data Block 13 Wirkarbeit der 3 Phasen Total active energy of 3 phases*
15 28, 29 Data Block 14 Scheinleistung der 3 Phasen Total apparent power of 3 phases
16 30 Block 1 property byte Property von Strom Phase L1 PB of phase 1 current
31 Block 2 property byte Property von Strom Phase L2 PB of phase 2 current
17 32 Block 3 property byte Property von Strom Phase L3 PB of phase 3 current
33 Block 4 property byte
Property von Strom der
höchstbelasteten Phase
PB of max current in phase under
highest load
18 34 Block 5 property byte Property von Strom im Neutralleiter PB of current in neutral conductor
35 Block 6 property byte Property von Verkettete Spannung L1 nach L2 PB of phase to phase voltage L1 to L2
19 36 Block 7 property byte Property von Verkettete Spannung L2 nach L3 PB of phase to phase voltage L2 to L3
37 Block 8 property byte Property von Verkettete Spannung L3 nach L1 PB of phase to phase voltage L3 to L1
20 38 Block 9 property byte Property von Sternpunktspannung L1 PB of phase to neutral voltage L1
39 Block 10 property byte Property von Sternpunktspannung L2 PB of phase to neutral voltage L2
21 40 Block 11 property byte Property von Sternpunktspannung L3 PB of phase to neutral voltage L3
41 Block 12 property byte
Property von Mittelwert des
Leistungsfaktors der 3 Phasen
PB of average of power factors of 3 phases
22 42 Block 13 property byte Property von Wirkarbeit der 3 Phasen
a)
PB of total active energy of 3 phases
a)
a) Nur 2 bytes des 4 byte langen Datenpunkts werden übertragen
(Bereich: 0 - 65535 MWh)
43 Block 14 property byte Property von Scheinleistung der 3 Phasen PB of total apparent power of 3 phases
Basic Data Type 3 Registers and Default Data Points
a) Only 2 bytes of the 4 byte data point will be communicated (range: 0 -
65535 MWh)
