8 – 2
8.2 Hilfsstromschalter
Leitungsnummer
Wire no.
13
24
S1
X6.12
X6-12
X6.10
X6-10
X6.11
X6-11
X6.9
X6-9
13
42
S2
X6.4
X6-4
X6.2
X6-2
X6.3
X6-3
X6.1
X6-1
13
42
S3
X5.10
X5-10
X5.8
X5-8
X5.9
X5-9
X5.7
X5-7
13
42
S4
X5.6
X5-6
X5.4
X5-4
X5.5
X5-5
X5.3
X5-3
S1, S2
Optionale Hilfsstromschalter
Optional auxialiary switches
Intern
Internal
S3, S4
Optionale Zusatz-Hilfsstromschalter
Optional auxiliary switches
0136-01_u
Leitungsnummer
Wire no.
Klemmen
Terminals
Klemmen
Terminals
S1
S2
S3
S4
8.2 Auxiliary switches
