Siemens WL Series User Manual

13 – 4
Installing the selector knob
13.3 Updating the options label
Knebelschalter einsetzen
13.3 Ausstattungsschild aktualisieren
Hinweis NOTICE
Nach dem Einbau zusätzlicher Komponenten folgende Anga-
ben mit einem weißen, wisch- und wasserfesten Stift ankreu-
zen!
After installing additional components, mark with a “x” the fol-
lowing data using a black or blue indelible ink pen!
Voltage
Spannung
Power consumption
Leistungsaufnahme
Catalog No.
Bestell-Nr.
Motor-operated mechanism
Motorantrieb
24 VDC / 30 VDC 110 W WLELCMTR24
48 VDC / 60 VDC 120 W WLELCMTR48
110-127 VAC / 110-125 VDC 150 W WLELCMTR120
208-240 VAC / 220-250 VDC 130 W WLELCMTR240
Motor-operated mechanism
with motor disconnect s
witch
Motorantrieb mit Motorab-
stellschalter
24 VDC / 30 VDC 110 W WLELCMTR24S
48 VDC / 60 VDC 120 W WLELCMTR48S
110-127 VAC / 110-125 VDC 150 W WLELCMTR120S
208-240 VAC / 220-250 VDC 130 W WLELCMTR240S
4
3
2
1
Front Panel
Bedienpult
3,0 x 0,6
Siemens Energy & Automation, Inc., Grand Prairie, TX 75050, USA
Charging Motor
Remote Close Coil
X5-2 (+)
X5-1 (-)
X6-7 (+)
X6-8 (-)
240
250
VAC
VDC
120
125
VAC
VDC
240
250
VAC
VDC
120
125
VAC
VDC
VAC
VDC
120
125
VAC
VDC
1st Shunt Trip
UVR
2nd Shunt Trip
Remote Reset
X6-13 (-)
X6-14 (+)
X5-11 (-)
X5-12 (+)
X9-1 (-)
X9-2 (+)
X8-13 (-)
X8-14 (+)
Ready to Close Switch
X6-5
X6-6
240 VAC
4A
240 VAC
1st Shunt Trip Switch
X9-7
X9-8
240 VAC
UVR Switch
X9-10
X9-11
52a 1st Aux. SW. 52b
X6-3
X6-4
X6-11
X6-12
X6-1
X6-2
X6-9
X6-10
X5-5
X5-6
X5-9
X5-10
X5-3
X5-4
X5-7
X5-8
52a 2nd Aux. SW. 52b
240 VAC ,
Bell Alarm
240 VAC
5A
X9-13
X9-14X9-12
3A
3A
Assembled in USA
10 A / 125 VDC , 0.5 A / 24 VDC , 3A
0131_nu
