6 – 6
6.4 Closing
6.5 Opening the circuit breaker
6.4 Einschalten
6.5 Ausschalten
CLOSE button / EIN-Taster Electrical Closed / Elektrisch EIN Remote activation / Fernbetätigung
(The storage spring will be recharged by the motor-operated mechan
ism immediately after the circuit breaker has closed)
(Unmittelbar nach dem Einschalten wird der F
ederspeicher durch den Motorantrieb wieder gespannt)
OPEN button / AUS-Taster Remote activation / Fernbetätigung
Indicators
Zustandsanzeigen
or
oder
or
oder
Indicators
Zustandsanzeigen
Without motor-operated mechanism
Ohne Motorantrieb
With motor-operated mechanism
after 10 seconds
Mit Motorantrieb nach 10 s
or
oder
Indicators
Zustandsanzeigen
Without motor-operated mechanism
Ohne Motorantrieb
With motor-operated mechanism
Mit Motorantrieb
