21 – 3
Baugröße II
(1) Zylinderkopfschraube M6 x 20
(2) Selbstschneidende Schraube M4 x10
(3) Zylinderkopfschraube M6 x 20
Baugröße III
0697_nu
1
2
3
2
2
2
4
4
4
4
5
PH 2
3,2 Nm
28 lb-in
Gr. / Size
5
8 Nm
71 lb-in
(1)
(2)
(3)
0697-2_nu
1
2
Frame size II
(1) Cheese-head screw M6 x 20
(2) Self-tapping screw M4 x10
(3) Cheese-head screw M6 x 20
Frame size III
1
