WL Circuit Breaker Accessory Ratings
Position Signal Contact on the Guide Frame (TOC)
Breaker position: Connected position 3 form C 1 form C 6 form C
Test position 2 form C 1 form C 0 form C
Disconnected position 1 form C 1 form C 0 form C
Contact rating
Alternating current
50/60Hz
Rated operational voltage 120V
Rated operational current, continuous 10A
Rated operational current, making 6A
Rated operational current, breaking 6A
Direct current Rated operational voltage 24V 24V, 48V, 125V 250V
Rated operational current, continuous 6A 1A 1A
Rated operational current, making 6A 0.22A 0.11A
Rated operational current, breaking 6A 0.22A 0.11A
