5 – 27
Hilfsstromstecker aufsetzen
L
(1) Hilfsstromstecker
(2) Fest
einbauschalter: Messerleiste
Einschubschalter: Schleifk
ontaktmodul
5.4.4 Leitungsverlegung am Einschubrahmen
(1)
1
2
(2)
Attaching the secondary disconnect blocks
(1) Auxiliary connector
(2) F
ixed-mounted breaker: Breaker secondary disconnect block
Draw-out breaker: Gu
ide frame secondary disconnect block
5.4.4 Wiring in guide frame
