7 – 23
Lifting Point (Cradle and
Breaker) Do not lift by other
points.
Closed door racking
Lifting Point (Cradle
only) Do not lift by other
points.
34.80
[884]
Withdrawn position
15.7
[398]
19.13
[486.0]
Minimum free space for
breaker racking
6.43
[163.4]
0.75
[19.0]
0490-4_ul
