1.4 MAIN WORKING PARTS - WITH OPTIONAL “LOADER UNIT”
Fig. 9
A - master switch / emergency button
B
- keyboard
C
- display
D - clamp optical reader
D1-
clamp cutter side (Automatic)
E
- optical reader clamp knob
F
- key gauge – optical reader side
H
- cutter (Fig. 8)
I
- cutter shield (Fig. 8)
L
- optical reader
P
- power input (Fig. 8)
Q - serial port (Fig. 8)
S
- X axis carriage
T
- Y axis front panel
U
-
protective shield
V
- keys tray
V1-
swarf tray
V2 -
key slide
W -
glove compartment
Z
- loader
D741756ZB
Set Feeder
Operating Manual UC199
