5.7 [4] CALIBRATIONS
The machine leaves the Silca workshops perfectly calibrated and ready for use. If it is necessary to check, bear
in mind that:
Themachinehasapartial“self-setting”systemthatusestemplates(Ch.1.6)andspecicprocedures.
From the main menu press the SHIFT + STOP keys to zero the axes, then:
Operational keys: use the arrow keys [Up/Down] to move the cursor to the option required and press ENTER.
1- Copy from original
2- Copy with adjust.
3- Queue from PC
4- Calibrations >>
with the pointer on position 3 press ENTER to see on the display:
1- Cutting clamps
2- Cutter
3- Adaptors
5.7.1 CLAMPS CALIBRATION
In the circumstances listed below (see events) it may be necessary to re-set one or all calibration. This operation
is semi-automatic and requires close attention to the instructions listed below.
EVENT
MACHINE
ZEROES
CALIBRATIONS
STANDARD
CLAMPS
AUTMATIC
CLAMP
Electronic board replacement
NO YES YES
Replacement of the Optical Reader unit
NO YES YES
Replacement of sensors
YES YES YES
Replacement of the cutter shaft (*)
YES YES YES
Replacement of the ball screws (*)
YES YES YES
L100 clamp replacement / Cutting
(with a new one of the same type)
NO YES YES
L100 clamp replacement / Reading
(with a new one of the same)
NO YES YES
Re-sharpening of existing cutter and/or
cutter replacement (with a new one of the same type)
NO YES YES
(*) Solo from Silca S.p.A. or Silca Authorized After-Sales Service Centres.
Select “Cutting clamps” and press ENTER.
Clamps
L100 - Standard
L1 - Autom. Feeder
