5.8 [5] MAINTENANCE
1) Enter the “Maintenance” menu 5.
Operational keys: use the arrow keys [Up/Down] to move the cursor to the option required and press
ENTER.
1- Copy from original
2- Copy with adjust.
3- Queue from PC
4- Calibrations >>
5- Maintenance
6- Options
The display will show:
1- Test
2- Machine ‘0’ point
3- Loader unit
5.8.1 TEST
There is an on board TEST menu that should be used to verify the cause of any breakdown that may occur to
the machine.
Pointer on position 1 - press ENTER, the display will show:
1- Optic reader
2- X axis motor
3- Y axis motor
4- B axis motor >>
5- Cutter motor
6- X axis sensor
7- Y axis sensor
8- B axis sensor
9- Shield micro
10- Automatic clamp
11- Key sensor
12- Magnet
13- Keyboard
14- Display
15- Serial port
16- Battery status
Operational keys: use the arrow keys [Up/Down] to move the cursor to the option required and press ENTER.
TEST1: OPTICAL READER
Carefully follow the instructions that are on the machine’s display. Check that the optical reader’s status changes
from OFF to ON.
1 OPTIC READER
Close shield
and press START.
Status:OFF
NOTE: if the OFF/ON transition is not made, contact Silca’s Technical Assistance Dept.
Operating Manual UC199
Copyright Silca 2012
51
