TEST 2: X AXIS MOTOR
2 MOTOR X
Arrows keys to
move axis.
Carefully follow the instructions on the machine’s display. Check that the X axis carriage moves, (use the [< >]
keys).
ATTENTION: during this test function all end of run controls are disactivated; avoid moving
the carriage up against its mechanical stops.
NOTE: if the motor does not start, contact Silca’s Technical Assistance Dept.
TEST 3: Y AXIS MOTOR
3 MOTOR Y
Arrows keys to
move axis.
Carefully follow the instructions on the machine’s display. Check that the Y axis carriage moves, (use the arrow
keys [Up/Down]).
ATTENTION: during this test function all end of run controls are disactivated; avoid moving
the carriage up against its mechanical stops.
NOTE: if the motor does not start, contact Silca’s Technical Assistance Dept.
TEST 4: B AXIS MOTOR
This test can be carried out only when an automatic clamp (optional) is installed on the machine.
4 MOTOR B
Arrows keys to
move axis.
Use the arrow keys [up/down] to check movement of the jaws on the automatic clamp.
NOTE: if the motor does not start, contact Silca’s Technical Assistance Dept.
TEST 5: CUTTER MOTOR
Carefully follow the instructions on the machine’s display. Check that the cutter motor is working.
5 CUTTER MOTOR
START key to
activate motor.
NOTE: if the cutter motor does not turn, contact Silca’s Technical Assistance Dept.
Operating Manual UC199
Copyright Silca 2012
