TEST 6: X AXIS SENSOR
6 SENSOR X
Press arrows keys
to move axis.
Status:OFF
Use the [< >] keys. Move the carriage to the left to reach ON status.
NOTE: if the ON/OFF transition is not made, contact Silca’s Technical Assistance Dept.
TEST 7: Y AXIS SENSOR
7 SENSOR Y
Press arrows keys
to move axis.
Status:OFF
Use the arrow keys [Up/Down]. Move the cutter support downwards to reach ON status
NOTE: if the ON/OFF transition is not made, contact Silca’s Technical Assistance Dept.
TEST 8: B AXIS SENSOR
This test can be carried out only when an automatic clamp (optional) is installed on the machine.
8 SENSOR B
Press arrows keys
to move axis.
Status:OFF
Use the arrow keys [Up/Down].
NOTE: if the ON/OFF transition is not made, contact Silca’s Technical Assistance Dept.
TEST 9: PROTECTIVE SHIELD MICROSWITCH
9 SHIELD MICRO
Open & close
shield
Status:ON
Lift and lower the protective shield checking that the machine’s display indicates OFF to ON.
NOTE: if the ON/OFF transition is not made, contact Silca’s Technical Assistance Dept.
TEST 10: AUTOMATIC CLAMP - OPTIONAL
10 AUTOMATIC
CLAMP DETECTED
<INSTALLED>
Indicateswhethertheautomaticclamp(optional)isttedornot.
ATTENTION: turnthekey-cuttingmachineoffbeforettingorremovingtheautomaticclamp.
