Fig. 28
Fig. 29
Fig. 30
ATTENTION: always replace both jaws. Mixed jaws may be used only for keys with a
thickness of 2.0 mm to 2.8 mm.
NO!
type: Upper jaw A + Lower jaw B
YES
type: Upper jaw A + Lower jaw A
type: Upper jaw B + Lower jaw A type: Upper jaw B + Lower jaw B
type: Upper jaw 2,0÷2,8 + Lower jaw B type: Upper jaw 2,0÷2,8 + Lower jaw A
NOTE: instructions on how to replace the jaws on the Automatic clamp are given in ch.7.7.
