CPU, continued
CPU card
specifications
Table 2-9 shows the battery current draw for the CPU card.
Table 2-10 shows the maximum draw over the voltage range.
Note: CPU InfoAlarm supervisory and alarm current draws are both the same as the supervisory current
draw.
Table 2-9. Battery standby (24 V)
Configuration Supervisory current draw Alarm current draw
RUI disabled 124 mA 173 mA
RUI enabled - no load 149 mA 198 mA
RUI enabled - full load 176 mA 225 mA
Table 2-10. Maximum draw over voltage range
Configuration Supervisory current draw Alarm current draw
RUI disabled 144 mA 208 mA
RUI enabled - no load 167 mA 226 mA
RUI enabled - full load 186 mA 248 mA
