48-LED Module, continued
48-LED Module
specifications
Table 2-17. 48-LED Module current specifications
Standby current Current
LED controller circuit 20 mA
Add to above for each additional LED that is on 1.89 mA
Total current for fully loaded 48-LED Module 111 mA
Maximum alarm current
Current
LED controller circuit 20 mA
Add to above for each additional LED that is on 2.39 mA
Total current for fully loaded 48-LED Module 135 mA
