A-9
Alarm Cutout Timer
Overview The Alarm Cutout Timer allows you to set a duration (up to 10 minutes) that specifies how
long signals sound following an alarm. For example, with this option set at two minutes,
building signals sound for two minutes and then automatically stop. After the signals stop, the
alarm condition remains active at the panel.
Note: The default setting is not enabled. This option must be enabled for Canadian jobs
Enabling Alarm
Cutout Timer
To enable the Alarm Cutout Timer, do the following:
1. Click on the Panel tab at the top of the programmer.
2. Click on the System Options tab at the bottom of the programmer. A screen similar to the
one shown below appears.
3. Click on the checkbox to the right of Alarm Cutout Timer. Specify the timer value in the
Seconds box to the right of the checkbox.
Figure A-9. System Options: Setting the Alarm Cutout Timer
