8-6
Earth fault searching from the front panel
Overview This section describes how to conduct an Earth Fault Search, from selecting the appropriate
access code to correcting the fault.
Access level
selection
The panel must be at the appropriate access level (1, 2, 3, or 4) in order to run diagnostics. To
get to the correct access level:
1. Press the Menu button. The following message comes up (press the Next or Previous
buttons, if necessary, to display it):
2. Press the Enter button. Now you are prompted to log in or log out.
3. Press the "1" key on the numeric keypad to log in, so that the passcode prompt comes up.
4. Enter the passcode and press the Enter button. ACCESS GRANTED displays briefly on
the LCD, and then the display goes back to:
You can now open the diagnostic menu as described in the next topic.
Starting the Earth
Fault Search
To start an Earth Fault Search:
1. If necessary, press the Menu button to access the menus.
2. Press the Previous or Next buttons until the diagnostic functions option appears:
3. Press the Enter button. Then press Next or Previous buttons until the Earth Fault Search
option appears:
4. Press the Enter button. The following options become available when you press the Next
and Previous buttons:
The search types are described below. When you have determined what kind of search to
initiate, display its option (one of the three shown above) and press the Enter button. Each
option is described below.
Press <NEXT> or <PREVIOUS> to scroll
Change Access Level?
1=Login 2=Logout
CURRENT ACCESS LEVEL = x
Enter a Passcode followed by <ENTER>
1=Login 2=Logout
CURRENT ACCESS LEVEL = y
Press <NEXT> or <PREVIOUS> to scroll
Diagnostic Functions?
Press <NEXT> or <PREVIOUS> to scroll
Earth Fault Search?
Press <NEXT> or <PREVIOUS> to scroll
Location Search
Press <NEXT> or <PREVIOUS> to scroll
IDNet Channel Search
Press <NEXT> or <PREVIOUS> to scroll
Last Search Result
To Next Page
