3-4
One-bay 4010ES Panels, continued
Optional modules In addition to the basic modules, optional modules can be installed inside the one-bay 4010ES
panels. The types of modules available depend on the panel configuration as well as the
accessibility and availability of the power distribution interface (PDI) blocks.
Note: Out of four PDI blocks in the top bay PDI card, three are available since the MSS card utilizes one
(Figure 2-5).
Table 3-1 lists the optional modules that can be installed inside the different configurations of
the 4010ES panels. Refer to the user manual associated with each card for specifications and
installation instructions. The list of these manuals is available in Table 4-3 in Chapter 4,
“Orderable Panels and Devices.”
Note: 1. Consult your local sales office to determine which modules are available in your area.
2. Physical bridge cards must also be installed with a network interface card. Therefore, the 4010ES
one-bay systems do not have enough option card space left to install a physical bridge after a NIC is
added.
Table 3-1. Optional modules
Optional modules Description Blocks
4010-9818 Network Media Card Wired (Mounts on 4010-9902 and 4010-9922) none
4010-9819 Network Media Card Fiber Optic (Mounts on 4010-9902 and 4010-9922) none
4010-9901 VESDA Interface Card 1
4010-9902 and 4010-9922 4120 Network Interface Card 2
4010-9903 and 4010-9924
(Note 2)
4120 Network Interface w/ Modem physical Bridge Style 4 2
4010-9904 and 4010-9925
(Note 2)
4120 Network Interface w/ Modem physical Bridge Style 7 2
4010-9905 and 4010-9926
(Note 2)
4120 Network Interface TCP/IP physical Bridge Style 4 3
4010-9906 and 4010-9927
(Note 2)
4120 Network Interface TCP/IP physical Bridge Style 7 3
4010-9908 4-Point Flat AUX Relay (2 A) 1
4010-9909 City Connect Card with Disconnect Switches (MSS mounted) none
4010-9910 City Connect Card without Disconnect Switches (MSS mounted) none
4010-9911 Alarm Relay Card (MSS mounted) none
4010-9912
SDACT Card
(Mounts in top bay Block D only)
1
4010-9913 SafeLinc Internet Interface (FPII) Card 2
4010-9914 Building Network Interface Card (BNIC) 2
4010-9916 25 VDC Voltage Regulator Card 1
4010-9917 MX Digital Loop Card (international models only) 2
4010-9918 Dual RS232 Card 1
4010-9919
TrueInsight Remote Service Gateway (Perle)
(mounts on dead front)
none
4010-9920 8 Zone Initiating Device Circuit, Class B 2
4010-9921 8 Zone Initiating Device Circuit, Class A 2
4010-9929 IDNet 2+2 Card 1
