3-3
One-bay 4010ES Panels, continued
Overview
Figure 3-2. One-Bay 4010ES Panel
Without 48-LED Module
With 48-LED Module
Glass Door
Glass Door
Dead
Front
Dead
Front
CPU
CPU
Back
Box
Back
Box
Option Card
Mounting Space
Option Card
Mounting Space
48-LED
Module
