4-2
Panels
One-bay 4010ES
Panels
Two-bay 4010ES
Panels
Table 4-1. One-bay 4010ES systems
Panel PIDs
Panel
color
Panel language
and AC voltage
Panel components
4010-9401 Red
English
120V
CPU with a 2 x 40
display and a piezo
Standard
operator
interface
MSS with an IDNet
channel
Three free
option blocks
---
4010-9402 Platinum
4010-9501 Red
English
220V-240V
4010-9502 Platinum
4010-9403 Red
English
120V
48-LED Module
(door-mounted)
4010-9404 Platinum
4010-9405 Red
French
120V
4010-9406 Platinum
4010-9503 Red
English
220V-240V
MSS (No IDNet)
One free
option block
One MX Loop
Option Card pre-
installed (4010-
9917)
4010-9504 Platinum
Table 4-2. Two-bay 4010ES systems
Panel PIDs
Panel
color
Panel
language and
AC voltage
Panel components
4010-9421 Red
English 120V
CPU with a 2 x 40
display and a piezo
Standard operator
interface
MSS with an
IDNet channel
One IDNet 2+2 Card
pre-installed
(4010-9929)
4010-9422 Platinum
4010-9521 Red
English
220V-240V
4010-9522 Platinum 10 free
option
card blocks
4010-9425 Red
English 120V
CPU
InfoAlarm interface
(display and piezo)
One IDNet 2+2 Card
pre-installed (4010-
9929)
4010-9426 Platinum
One IDNet 2+2 Card
pre-installed (4010-
9929)
4010-9525 Red
English
220V-240V
11 free
option card
blocks
--
4010-9526 Platinum --
4010-9523 Red
CPU with a 2 x 40
display and a piezo
Standard operator
interface
MSS
(No IDNet)
7 free option
card blocks
Two MX Loop Option
Cards pre-installed
(4010-9917)
4010-9524 Platinum
4010-9527 Red
CPU
InfoAlarm interface
(display and piezo)
9 free option
card blocks
One MX Loop Option
Card pre-installed
(4010-9917)
4010-9528 Platinum
4010-9529 Red
7 free option
card blocks
Two MX Loop Option
Cards pre-installed
(4010-9917)
4010-9530 Platinum
4010-9423 Red
English 120V
CPU with a 2 x 40
display and a piezo
Standard operator
interface
MSS with an
IDNet channel
10 free
option card
blocks
One IDNet 2+2 Card
pre-installed (4010-
9929)
48 LED Module (door
mounted)
4010-9428 Platinum
4010-9430 Platinum French 120V
