Software modes, continued
Software modes Master Bootloader Interface Mode:
This interface should be used when the Master executable is not functioning. It downloads the
CPU Exec firmware and the CFG.TXT file to the CPU via the serial or the Ethernet port.
Figure 7-3. Bootloader interface
Laptop/PC running
terminal emulation software
4010ES Panel
running Bootloader
serial download or
standard Ethernet cable
Laptop/PC running
programming file transfer
