Symbol Description
Selected AIS target, indicated with square corners
around the target symbol.
Lost AIS target, indicated with a line on the target
symbol. The symbol is located at the last received
position from the target
AIS AtoN (Aids To Navigation) target symbol.
AIS AtoN (Aids To Navigation) target symbol.
AIS AtoN (Aids To Navigation) dangerous target. The
yellow color is shown when the radar palette is
black/red or black/green.
AIS AtoN (Aids To Navigation) dangerous target. The
purple color is shown when the radar palette is
white/red.
AIS AtoN (Aids To Navigation) dangerous target. The
red color is shown when the radar palette is black/
yellow.
AIS SART 'active' icons are red.
AIS SART 'tests' icons are green.
AIS | GO XSE/XSR Operator Manual
143
