Chart sharing
When connected to the Ethernet network, 12 inch GO units can
access and display Chart data from a card inserted into other 12
inch units and other display units capable of sharing charts through
the network. Charts shared over the network become selectable as
a chart source in the menu.
Selecting chart source
Available chart sources are listed in the menu.
If you have identical chart sources available, the system
automatically selects the chart with most chart details for your
displayed region.
Showing dual chart sources
If you have different chart sources available, you can show two
different chart sources simultaneously on a page that has two chart
panels.
Activate each chart page and select its source in the menu.
Vessel symbol
When the system has a valid GPS position lock, the vessel symbol
indicates vessel position. If no GPS position is available, the vessel
symbol includes a question mark.
If heading information is not available, the vessel icon orientates
itself using COG (Course over Ground).
Zooming the chart
The chart range scale and range rings interval (when turned on) are
shown on the chart panel. You change the scale by zooming the
chart in or out.
Panning the chart
You can move the chart in any direction by:
• Dragging your finger on the screen
Charts | GO XSE/XSR Operator Manual
35
