Echosounder settings
View sonar log
Used to view recordings. The log file is displayed as a paused image,
and you control the scrolling and display from the menu.
You can use the cursor on the image, measure distance, and set
view options as on a live image. If more than one channel was
recorded in the selected log file, you can select which channel to
display.
Structure depth offset
All transducers measure water depth from the transducer to the
bottom. As a result, water depth readings do not account for the
distance from the transducer to the lowest point of the boat in the
water or from the transducer to the water surface.
156
Echosounder | GO XSE/XSR Operator Manual
