Menu button
Displays the menu of the active panel. Use menu options to
customize the image. The panel menu options are further explained
later in this manual in each application chapter.
Instrument bar
The instrument bar displays information from sensors connected to
the system.
By default, the instrument bar is shown on the panel. You can turn
the instrument bar off.
You can select the predefined bar to be shown and you can change
the information displayed in the predefined bar. Refer to "Customizing
the instrument bar" on page 28.
Control bar
The control bar contains buttons for launching controllers or
features enabled in your system. The different controllers are
described in applicable chapters later in the manual.
22
Introduction | GO XSE/XSR Operator Manual
