Skyjack SJ12 E - Page 130

130
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 5 – Procedures Display Module
Code Description Cause Troubleshooting
127-LOAD_
ERRXX
L.CELL NO MSG
XX
The controller has detected a
communication issue with the load cell
sensor:
L.CELL NO MSG 28: Primary node or/
and redundant node has exited from
OPERATIONAL STATE;
L.CELL NO MSG 29: Primary node is in
fault internal state;
L.CELL NO MSG 2A: Redundant node is
in fault internal state;
L.CELL NO MSG 2C: eartbeat packets
are not received from primary node and/
or redundant node before the timeout of
4.2 s;
L.CELL NO MSG 2D: The nodes are in
OPERATIONAL MODE. PD01 packets
are not received from primary node and/
or redundant node before the timeout of
500 ms.
Check the wirings and the load cell.
128-LOAD_ERR
LOAD CELL
MISMXX
The controller has recognised an issue
with the load cell:
LOAD CELL MISM01: in the Primary
Node at least one load cell measures
values out of range;
LOAD CELL MISM02: the Primary Node
measures a weight over the maximum
admitted value;
LOAD CELL MISM03: in the Redundant
Node at least one load cell measures
values out of range;
LOAD CELL MISM04: the Redundant
Node measures a weight over the
maximum admitted value:
LOAD CELL MISM05: the Load cell
1 of Primary Node and load cell 1 of
Redundant Node measure different
weights;
LOAD CELL MISM06: the Load cell
2 of Primary Node and load cell 2 of
Redundant Node measure different
weights;
LOAD CELL MISM07: the Load cell
3 of Primary Node and load cell 3 of
Redundant Node measure different
weights;
Check the load cells.
129-JSTK_ERR JOYSTIC SAFETY
The controller has recognised an issue
on the SAFETY INPUT coming from the
joystick.
Check the SAFETY INPUT wire and
the CAN JOYSTICK parameter. If the
signal from the joystick is not ok,
replace the joystick.
If the signal from the joystick is ok,
replace the controller.
130-BRK1_ERR BRAKE RELEASE
The electric brakes are disengaged by
the user.
Re-engage the brakes.
