SJ12 E, SJ16 E, SJ20 E
241914ACA
Display Module Section 5 – Procedures
Code Description Cause Troubleshooting
131-AO ON
ANTI OVERRISE
ON
The anti overrising function is enabled.
As a consequence, the platform lifting is
inhibited.
Lower the platform.
132-AO ERR
CHECK ANTI
OVER.
The controller has recognised a
mismatch between the two inputs that
manage the anti
overrise.
Check the wiring and the anti overrise
switches.
133-TELEMATIC
TELEMATICS
STOP
The telematics disables the functions.
Driving, steering, lifting and lowering are
inhibited.
Check the telematics and the wiring.
134-LOWBATT
LOW BAT.-NO
TRAC
The battery charge level is too low for
driving.
Driving is inhibited.
Charge the battery.
135-OVER TILT
SLOPE CUT
DRIVXX
The machine is being driven over a too
steep slope:
SLOPE CUT DRIV01: driving forward and
up a too steep slope;
SLOPE CUT DRIV02: driving backward
and up a too steep slope;
SLOPE CUT DRIV03: driving backward
and down a too steep slope;
SLOPE CUT DRIV04: driving forward and
down a too steep slope;
Check the calibration of the tilt
sensor. Replace the controller.
138-SERVICE SERVICE MODE XX
Service mode is recognised:
SERVICE MODE 01: service mode
is active. Driving, steering, lifting and
lowering are inhibited. All outputs of the
Joystick are disabled.
SERVICE MODE 02: service mode is
active with diagnostic. Driving, steering,
lifting and lowering are allowed. All
outputs of the Joystick are available.
Exit the service mode. If service
mode input is inactive, check the
wiring.
139-PL EXT DECK EXTENDED
The platform deck is extended. As a
consequence driving is inhibited.
Retract the platform deck. If it is
already retracted, check the wiring.
140-LOW BATT LOW BAT.-NO LIFT
The battery charge level is too low for
lifting.
Lifting is inhibited.
Charge the battery.
141-TILT ERR TILT ERROR XX
The internal tilt sensor is faulty. The
hexadecimal value "XX" facilitates Zapi
technicians debugging the problem.
Replace the controller.
142-CHARGING CHARGER ON
The battery charger is charging the
battery. Driving, steering, lifting and
lowering are inhibited.
Disconnect the battery charger from
the master. Check the wiring.
143-DRV L.-POT
DRV LOCK-
POTHOXX
Error with the pothole:
DRV LOCK-POTHO01: pothole is
deployed when the platform is stowed.
DRV LOCK-POTHO02: pothole is not
deployed when the platform is lifted.
Driving and steering are disabled.
Check the state of the pothole. Check
the wiring.
144-CTRL ERR IIC BUS ERROR XX
The internal IIC bus is faulty. The
hexadecimal value "XX" facilitates Zapi
technicians debugging the problem.
Replace controller.
