Display Module Section 5 – Procedures
Code Description Cause Troubleshooting
202-CTRL ERR VDC LIN OVERV.
This fault is displayed when the controller
detects an overvoltage condition.
Overvoltage threshold depends on the
nominal voltage of the controller.
Nominal voltage 24 V, overvoltage
threshold 35 V.
As soon as the fault occurs, power
bridge and MC are opened. The
condition is triggered using the same
W interrupt used for under- voltage
detection, microcontroller discerns
between the two evaluating the voltage
present across DC-link capacitors:
If the alarm happens during the brake
release, check the line contactor
contact and the battery power cable
connection. Monitor the BATTERY
VOLTAGE reading by the TESTER
function, check it matches with the
voltage across +B and -B terminals.
If no problem can be found, replace
the controller.
206-CTRL ERR INIT VMN HIGH
Before closing the LC, the software
checks the power bridge voltage without
driving it. The software expects the
voltage to be in a "steady state" value.
If it is too high, this alarm occurs. The
hexadecimal value "XX" identies the
faulty phase:
81: phase U
82: phase V
83: phase W
Check the power cables
Check the impedance between U, V
and W terminals and -B terminal of
the controller.
Check the motor leakage to truck
frame.
If the motor connections are OK and
there are no external low impedance
paths, the problem is within the
controller. Replace it.
207-CTRL ERR INIT VMN LOW
Before closing the LC, the software
checks the power bridge voltage without
driving it. The software expects the
voltage to be in a "steady state" value.
If it is too low, this alarm occurs. The
hexadecimal value "XX" identies the
faulty phase:
01: phase U
02: phase V
03: phase W
Check the motor power cables.
Check the impedance between U, V
and W terminals and -B terminal of
the controller.
Check the motor leakage to truck
frame.
If the motor connections are OK and
there are no external low impedance
paths, the problem is within the
controller. Replace it.
208-CTRL ERR EEPROM KO
A HW or SW defect of the non-volatile
embedded memory storing the controller
parameters. This alarm does not inhibit
the machine operations, but it makes the
truck to work with the default values
Execute a CLEAR EEPROM
procedure. Switch the key off and
on to check the result. If the alarm
occurs permanently, it is necessary
to replace the controller. If the alarm
disappears, the previously stored
parameters will be replaced by the
default parameters.
209-CTRL ERR PARAM RESTORE
The controller has restored the default
settings. If a CLEAR EEPROM has been
made before the last key re-cycle, this
warning informs you that EEPROM was
correctly cleared.
A travel demand or a pump request
does cancel the alarm. If the alarm
appears at key-on without any
CLEAR EEPROM performed, replace
the controller.
210-CTRL ERR
WRONG RAM
MEM.
The algorithm implemented to check
the master RAM registers nds wrong
contents: the register is "dirty". This
alarm inhibits the machine operations.
Try to switch the key off and then
on again, if the alarm is still present
replace the logic board.
