Skyjack SJ12 E Service Manual

146
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 5 – Procedures Display Module
Name Unit of Measure Description
LOAD C.R
WEIGHT3
WEIGHT
(Kg)
Weight measured at the Redundant Load Cell 3 (not always present)
LOAD C.R ERROR OFF/ON see load cell protocol
LOAD C.R
MOTION
OFF/ON see load cell protocol
LOAD C.R W.10KG OFF/ON see load cell protocol
LOAD C.R OVER
W.
OFF/ON see load cell protocol
LOAD C.R UNDER
W
OFF/ON see load cell protocol
CTRAP HW
Number
(1)
Master motor: number of occurrences of hardware-detected overcurrent events.
TRUCK SPEED
(km/h)
km/h
(0.1 km/h)
Speed of the truck (it requires custom software embedding gear ratio and
wheels radius). Expressed in KPH
TRUCK SPEED
(mp/h)
mp/h
(0.1 km/h)
Speed of the truck (it requires custom software embedding gear ratio and
wheels radius). Expressed in MPH
ODOMETER (km)
km
(1 km)
Odometer: overall distance traveled by the truck.
LS ELEVATED
Number
(1)
Platform in elevated state.
LS LOAD CELL K kg (1 kg) Load estimation from the load cell data.
LS LOAD CELL L Pound (1 lb) Load estimation from the load cell data.
TRUCK MODEL
Number
(1)
Displays the Model that the controller is set to:
4: SJ12
5: SJ16
6: SJ20
TILT PITCH
Degrees
(0.01°)
reading of the internal tilt sensor in degrees for the Pitch Angle
TILT ROLL
Degrees
(0.01°)
reading of the internal tilt sensor in degrees for the Roll Angle
TILT STATUS OFF/ON Tilt sensor status.
TILT
TEMPERATURE
Celsius
(0.1 °C)
Temperature of the internal Tilt Sensor
OPERATION
MODE
Number
(1)
Operative mode.
0 = Emergency
1 = On
2 = Platform mode
3 = Base mode
ALARM BEEPER
Number
(1)
Alarm condition for beeper.
ALARM FLASHER
Number
(1)
Alarm condition for ashing light.
SPEED M. ACTIVE
Number
(1)
Speed mode active.
