Display Module Section 5 – Procedures
Name Unit of Measure Description
IQIMAX LIM BRK
Ampere
(1 A)
Slave motor: instantaneous value of the maximum current the inverter can apply
to the motor to satisfy a braking request. The value is evaluated basing on the
real-time conditions (inverter temperature, motor temperature, etc.).
MOT POWER
WATT
Watt
(1 W)
Slave Motor: Estimation of the power supplied to the motor.
STATOR FLUX
MWB
10-3 Weber
(0.1 mWb)
Slave Motor: estimation of the motor magnetic ux.
MOTION TORQUE
NM
Nm
(0.1 Nm)
Slave motor: estimation of the motor torque.
STEER ANGLE
Degrees
(1°)
Current steering wheel angle. When the steering is straight ahead STEER
ANGLE is zero.
TEMPERATURE
1
Celsius
(1 °C)
Temperature measured on the master-side power board.
This temperature is used for the HIGH TEMPERATURE alarm.
M65-M2 TEMP
Celsius
(1 °C)
Slave Motor: windings temperature.
This temperature is used for the MOTOR OVERTEMP alarm.
DC PUMP
CURRENT
Ampere
(1 A)
DC current of the pump motor.
DC PUMP VMN
Percentage
(1%)
Voltage applied to the pump motor.
Duty cycle of the PWM applied to the motor.
B2 LIFT B OFF/ON Status of the Base Mode Lift Input
B6 LOWER B OFF/ON Status of the Base Mode Lower Input
B7 B MODE OFF/ON Status of the Base Mode Active Input
B12 P MODE OFF/ON Status of the Platform Mode Active Input
B8 DIAGNOST OFF/ON Status of the Diagnostic Active Input
B3 ELEVATED OFF/ON Status of the Mast Position Limit Switch
B11 BRK REL OFF/ON Status of the Emergency Brake Release Switch
B4 TILTED OFF/ON Status of the External Tilt Switch
A8 CHARGER OFF/ON Status of the Battery Charger, When ON function is diabled
A23 TELEMAT OFF/ON Status of the Telematics Input
B22 SET EVP2
Percentage
(1%)
Setpoint of the proportional electrovalve EVP2, on output NEVP2 B22. (Brake
Release Relay)
B16 EV5 OFF/ON Spare
B17 EV6 OFF/ON Spare
B18 EV7 OFF/ON Status of the EV7 Output (Power LED) Base E-Stop
B20 EV8 OFF/ON Status of the EV8 Output (Flashing Lights)
B21 EV9 OFF/ON Status of the EV9 Output (Horn)
JOYD 1:DRIVE M OFF/ON Status of the Digital Input at the Platform Joystick for Drive Mode
JOYD 2:LIFT M OFF/ON Status of the Digital Input at the Platform Joystick for Lift Mode
